BLS-2856
Diameter: p28
High quality NdFeB magnet used to sustain high temperature.
Silicon Steel Sheets used have high permeability, but low in iron loss
Recorded 92% high efficiency in certain models.
Every single Savox brushless motor is dynamic balanced during production,
@thus vibration and noise is minimized to extend operating life time.
Replaceable rotor design provides easy and simple DIY work for professional
@players.
One-piece CNC case design to enhance the durability and hardness at the
@same time avoiding fall-offs of front and end bells during the runs.
Download Specification
Dimension
Shaft Size (mm)
RPM/V(KV)
Continuous Current (A)
p27.6 x 56 mm (p1.09 x 2.21 inch)
p3.17
1600
15
Weight (w/wire)
Voltage
2850
30
?gm. (oz)
4-12 NiCd/NiMH
2-3s LiPo
2800
40
Power Range
Max. 576 W (15sec.)
