HT35/19M, HT34/19M, HT32/19M, HT35/22M
Model No. |
Staple Dimension |
Magazine Capacity |
Crown
(mm) |
Length
(mm) |
HT35/19M |
34.7 |
15&18 |
100 |
HT34/19M |
34 |
16&19 |
100 |
HT32/19M |
32 |
15&18 |
100 |
HT35/22M |
34.7 |
18&22 |
100 |
35/19M, 32/19M, 34/19M, 35/22M
Model No. |
Crown (mm) |
Wire Size (mm) |
Length (mm) |
35/19M |
34.70 |
2.3x0.9 |
15 & 18 |
32/19 M |
32.00 |
1.9x0.9 |
15 & 18 |
34/19 M |
34.00 |
2.3x0.9 |
15 & 19 |
35/22 M |
34.70 |
2.3x0.9 |
18 & 22 |
|
|
|
 |
| |
HT35/19M, HT34/19M, HT32/19M, HT35/22M：
35/19M, 32/19M, 34/19M, 35/22M：
|
390x115x295mm
1.9KGS/ 4.18LBS
Pneumatic:
Manual:
Air Pressure: |
342x115x220mm
2.20KGS/ 4.85LBS
342x115x220mm
1.68KGS/ 3.70LBS
5~7BARS(70~100PSI) |
|
|
|
 |
 |
 |
 |
| |
Packaging
|
|
 |
| |
|
|
 |
| |
|
|
|
|
|
