Seam welding
Excellent solderability
Tri - stable Enable/Disable
TTL and/or cmos
compatible Low
power consumption |
| |
 |
| |
| MODEL |
SMA-751C |
SMA-751L |
SMA-751T |
| FREQUENCY
RANGE |
MHz |
0.5
~ 100 |
0.5
~ 156 |
1.0
~ 100 |
|
FREQUENCY STABILITY |
ppm |
A:100 B: 50 C:
25 |
|
TEMP RANGE: |
¢J |
|
|
OPERATING TEMP. |
0
~ 70 |
|
STORAGE TEMP. |
-55
~ 125 |
|
POWSER SUPPLY VOLTAGE |
V
DC |
+5.0
10% |
+3.3
10% |
+5.0
10% |
|
OUTPUT LEVEL |
|
CMOS |
TTL |
|
OUTPUT SYMMETRY |
% |
40
~ 60(at50%VDD) |
40
~ 60(at 1.4V DC) |
|
INPUT CURRENT |
|
10 ~ 9.99MHz |
mA
max |
10 |
7 |
15 |
|
10 ~ 19.99MHz |
15 |
7 |
20 |
|
20 ~ 31.99MHz |
25 |
12 |
30 |
|
32 ~ 49.99MHz |
35 |
20 |
40 |
|
0 ~ 79.99MHz |
50 |
25 |
50 |
|
80 ~ 99.99MHz |
60 |
30 |
60 |
|
100 ~ 125MHz |
80 |
40 |
80 |
|
RISE / FALL TIME |
|
0.5~ 31.99MHz |
ns
max |
10 |
10 |
10 |
|
32 ~ 49.99MHz |
6 |
10 |
5 |
|
50 ~ 79.99MHz |
5 |
8 |
5 |
|
80 ~99.99MHz |
5 |
5 |
5 |
|
100 ~ 156MHz |
4 |
4 |
4 |
|
OUTPUT LOAD |
15pf(50PF)
|
10TTL |
| ¡AGING |
ppm |
5 |
|
| |
|
|
| |
¡DThe
power supply voltage 2.8V,2.5V is
available.
The symmetry 45~55% is available.
¡DENABLE/DISABLE FUNCTION
| INN(PIN
1)OUTPUT(PIN3) |
| High(Open)Operating |
| Low
High impedance |
|
 |
| |
|
|
